Product Description

Leveraging on our technologically advanced infrastructural unit, we have been a reputed supplier of Single Phase Energy Meter With Phantom Loading to our highly honored clients. This meter is widely used in electrical machine lab as per the requirements of customers. It is fabricated using premium quality raw material and ultra modern machinery at our vendors unit in adherence with the global industrial norms and standards. Single Phase Energy Meter With Phantom Loading is known for its high quality, effectiveness, strength, sturdiness and precise design.

Made study of single phase energy meter with Phantom loading to study principle and construction of a Single Phase Energy Meter and also to conduct various tests regarding  energy metering and registering and also comparing it with actual energy Consumption using fictitious/ Phantom Loading.

The Experimental Setup consists of the following parts :

1.         One No. of  Moving Coil Voltmeter of Range 0-300V AC of size 96*96mm provided with Input Terminals.

2.         One No. of  Moving Coil Ammeter of Range 0-10A AC of size 96*96mm provided with Input Terminals.

3.         One No. of Single Phase Power Factor Meter of size 96*96mm provided with Input Terminals.

4.         Two Nos. of Single Phase Energy Meter (Induction type) of Range 230V/ 10A provided on the Front Panel.

            a)         Test Energy Meter

            b)         Sub-Standard Energy Meter

5.         One No. of Miniature Circuit Breaker of Range 230V/ 20 Amps (MCB/ DP) Provided on the Input Side.

6.         Circuit Diagram printed on Bakelite Sheet front panel With Instruments Connecting Terminals.

7.         Panel board of portable wooden panel box is in Tappered shape for better view angle.

8.         Dimensions : 470 x 460 x 620 mm (L x B x H)

9.         Power Requirement : Single Phase 230V AC.

1.         Singlepoint (4mm) Patchcords for Interconnections (Electrical).                       -     24 Nos.

2.         Instruction Manual (DOC 2407).                                                                          -     1 No.

1.         Stop Watch                                                                                                    -     1 No.

2.         Single Phase Variac 4Amp. (Model No. ME 2301)                                         -     1 No.

3.         Single Phase Variac 15Amp. (Model No. ME 2304)                                       -     1 No.

4.         Phase Shifting Arrangement (Model No. ME 2350)                                        -     1 No.
