HYDRAULIC TRAINER KIT WITH WORK STATION
Product Details:
- Measurement Range 0 - 100 bar
- Capacity Standard laboratory capacity
- Automation Grade Manual & Semi Automatic
- Accuracy 2%
- Voltage 220 - 315 Volt (v)
- Core Components Hydraulic Pump, Cylinders, Valves, Pressure Gauges, Hoses, Mounting Frame
- Model No HTK-WS2024
- Click to View more
X
HYDRAULIC TRAINER KIT WITH WORK STATION Price And Quantity
- 1 Unit
- Tabletop/Mobile Cart
- HYDRAULIC TRAINER
- 10+ Standard Practical Experiments
- Directional Control, Pressure Relief, Flow Control Valves
- ISO VG 46
- Overload Protection, Emergency Stop
- Grey & Blue (Typical)
- Gear Type Hydraulic Pump
- 10 LPM (Max)
- 1.5 Meter (Each)
- METAL
HYDRAULIC TRAINER KIT WITH WORK STATION Product Specifications
- 220 - 315 Volt (v)
- 2%
- Manual & Semi Automatic
- Mobile Workstation with Casters, Modular Design, Quick Connect Couplings, Multiple Experiment Capability
- Approx. 60 Kg
- METAL
- HTK-WS2024
- Hydraulic Pump, Cylinders, Valves, Pressure Gauges, Hoses, Mounting Frame
- Standard laboratory capacity
- 0 - 100 bar
- HYDRAULIC TRAINER
- Metal
- 1200 mm x 700 mm x 900 mm
- Ambient to 60C
- Educational Purpose
- Electric
- 50 Hz
- Analog & Digital Indicators
- HYDRAULIC TRAINER
- Tabletop/Mobile Cart
- HYDRAULIC TRAINER
- 10+ Standard Practical Experiments
- Directional Control, Pressure Relief, Flow Control Valves
- ISO VG 46
- Overload Protection, Emergency Stop
- Grey & Blue (Typical)
- Gear Type Hydraulic Pump
- 10 LPM (Max)
- 1.5 Meter (Each)
- METAL
HYDRAULIC TRAINER KIT WITH WORK STATION Trade Information
- 10 Unit Per Week
- Days
- Corrugated Box
- All India
- ISO
Product Description
ME 7652 - Hydraulic Trainer with Work Station
Technical Specification:
Hydraulic Components
- Pressure relief valve: Pilot-operated (1No.)
- Drip tray, steel : Size 1160 mm x 760 mm. (1No.)
- Pressure gauge: Glycerin-damped (1No.)
Indication range of: 0-100 bar
- Four-Way distributor : With five ports equipped with a pressure gauge (1No.)
Hydraulic Cylinder
- Double acting hydraulic cylinder: With a control cam (1No.)
- Piston diameter: 16 mm
- Piston rod diameter:10 mm
- Stroke length: 200 mm
Different type of valve
- 3/2 Way directional control valve: With hand lever actuation (1No.)
- 4/2 Way directional control valve: With hand lever actuation (1No.)
- 4/3 Way directional control valve: Closed-centre position, with lever actuation (1No.)
- Non-return valve
- Pilot-operated check valve: Pilot to open (1No.)
- Drip tray, steel : Size 1160 mm x 760 mm. (1No.)
- Pressure gauge: Glycerin-damped (1No.)
Indication range of:0-100 bar
- Four-Way distributor : With five ports equipped with a pressure gauge (1No.) - One-way flow control valve: With integrated check valve (1No.)
Suitable weight: Forvertical loading of hydraulic cylinder (1No.)
Mounting kit for weight:For realizing pulling and pushing load (1No.)
T-Connector with selfsealing coupling nipples (2 Nos.) and quick coupling socket (2Nos)
Profile plate anodized:1100x700 mm, with carriers, mounting aluminum frames and mounting accessories(To be fitted on to the hydraulic workstation)
Hydraulic Powerpack
External gear pumphaving a delivery rate of 2.5 lpm (approx.) @ 1400rpm operating pressure 60bar, coupled to a single-phase AC motor (230 VAC) having start capacitor andOn/Off switch and overload protection, Pressure relief valve adjustable from0-60 bar Oil reservoir, 25 litres capacity having sight glass, drain screw, airfilter, and P and T ports.
Hydraulic WorkstationTable
Hydraulic workstationwith 45 square mm aluminum profile legs, wooden work surface, and one pedestaldrawer unit having 5 drawers, each with handles and individual locks, onmetallic full panel drawer slide:
- Work table size: 1200mm(L) x 900mm(W) x 900mm(H),with fourcastor wheels including two lockable wheels at the front side,
- Drawer size (approx.): 460mm (L) x 495mm (W) x158mm (H) each, and overall size of drawer unit (Approx.) 470mm (L) x 495mm (W)x 825mm (H)
- Drawer slideheight : 85mm
Versatile Experimentation
This hydraulic trainer kit supports over 10 standardized practical experiments, giving students the opportunity to explore concepts such as flow rate, pressure regulation, and valve operations. The modular setup enables quick reconfiguration for different hydraulic circuits, fostering interactive and experiential learning.
Comprehensive Safety Features
Safety is prioritized through overload protection and an emergency stop, ensuring user protection during operation. The system operates reliably under a range of voltages (220-315V) and includes standardized hydraulic oil (ISO VG 46), making it suitable for classroom and lab use without safety compromise.
User-Friendly and Mobile Design
The workstation is designed for both tabletop and mobile cart installations. Its casters and modular components allow easy movement and rapid setup, while quick connect couplings simplify hose connections, making it accessible for various educational scenarios and laboratory layouts.
FAQs of HYDRAULIC TRAINER KIT WITH WORK STATION:
Q: How does the hydraulic trainer kit enhance practical learning in educational settings?
A: The kit provides hands-on experience with hydraulic systems by enabling students to perform over 10 standard practical experiments, covering control valves, pressure regulation, and flow measurement, thus bridging theoretical concepts with practical skills.Q: What is the installation process for the hydraulic trainer kit?
A: The kit is designed for easy installation on a tabletop or mobile cart. Its modular construction and quick-connect couplings allow users to set up or reconfigure the system efficiently without specialized tools.Q: Which safety features are included in the workstation?
A: It is equipped with overload protection and an emergency stop function, ensuring user safety during all phases of operation. These safeguards help prevent accidents and equipment damage in laboratory environments.Q: What types of valves and instruments are integrated into the kit?
A: The trainer includes directional control, pressure relief, and flow control valves, along with gear type hydraulic pump, pressure gauges, and both analog and digital indicators to monitor system parameters accurately.Q: Where can the hydraulic trainer kit be used effectively?
A: It is ideal for educational institutions, technical schools, laboratories, and training centers in India, providing a comprehensive platform for instructional hydraulic experiments.Q: What are the main benefits of using this trainer kit for students?
A: Students benefit from interactive, hands-on understanding of hydraulic principles, improved technical competency, and exposure to real-world equipment similar to industry standards.Q: How is maintenance carried out for this hydraulic workstation?
A: The kits modular design, accessible components, and standardized parts (such as hydraulic oil and hoses) make routine maintenance straightforward, ensuring long-lasting reliability and minimizing downtime.Tell us about your requirement
