Cut Section Model for Pneumatic Components
38000 INR/Unit
Product Details:
- Automation Grade Manual
- Model No PCM-01
- Power Source Manual (no power required)
- Feature Sectional View for Internal Component Visualization
- Core Components Cut Section of Pneumatic Valves, Cylinders, and Connectors
- Temperature Range Ambient
- Equipment Materials Acrylic and Metal
- Click to View more
X
Cut Section Model for Pneumatic Components Price And Quantity
- 1 Number
- 38000.00 - 60000.00 INR/Unit
- 38000 INR/Unit
Cut Section Model for Pneumatic Components Product Specifications
- Ambient
- Cut Section of Pneumatic Valves, Cylinders, and Connectors
- Demonstration, Teaching Aids for Pneumatics, Technical Training
- Sectional View for Internal Component Visualization
- Acrylic and Metal
- Manual (no power required)
- Approx. 2-5 kg
- Educational Training Model
- PCM-01
- Manual
- Physical Cut-Section Model
- Approx. 30cm x 20cm x 15cm
Cut Section Model for Pneumatic Components Trade Information
- All India
- ISO
Product Description
ME 7643 - Cut Section Model for Pneumatic Components
Following Cut sectionModel of Pneumatic components mounted on
MS powder coted sheet& fitted on suitable frame:-
Filter
Oil/Water Separator
Ball valve
Unloader valve
5/2 Single solenoidvalve
Relay valve
Air drier
Filter/ Regulator/Lubricators (FRL)
Single acting cylinder
Double acting cylinder
Manifold
Comprehensive Visualization Tool
With its transparent and metallic cut section, this educational model effectively displays the internal structure and function of pneumatic elements. Tailored for diploma, ITI, and engineering-level students, it provides a sectional view that enhances understanding of complex mechanisms essential in pneumatic systems.
Sturdy and Functional Design
The model's smooth, corrosion-resistant finish and robust acrylic-metal construction guarantee long service life and reliability. Delivered factory assembled for easy deployment, its compact desktop/tabletop dimensions allow for convenient demonstration in classroom and lab settings.
Ideal for Hands-On Training
Created as a physical cut-section model, PCM-01 is an invaluable teaching aid. It enables interactive learning and demonstration of pneumatic technologies, making it a key component for technical training and vocational skill development.
FAQ's of Cut Section Model for Pneumatic Components:
Q: How is the Cut Section Model used for educational purposes in technical training centers?
A: The model is used in demonstrations and classroom teaching to visually explain the internal structure and operation of pneumatic components, aiding students in understanding real-world applications and system assembly without the need for live equipment.Q: What components are displayed in each Cut Section Model unit?
A: Each model typically features cut-section views of 2 to 4 core pneumatic elements, such as valves, cylinders, and connectors, allowing detailed visualization of their internal mechanisms.Q: When should this model be incorporated into a training curriculum?
A: The model is suitable for integration at diploma, ITI, and engineering levels, offering foundational and advanced students experiential learning during theory or practical sessions on pneumatics.Q: Where can the Cut Section Model be mounted during demonstrations?
A: Designed for desktop or tabletop use, the model's compact dimensions make it easy to place in classrooms, laboratories, and industrial training workshops for group or individual study.Q: What is the process for assembling or maintaining the model?
A: No assembly is required as the unit is factory assembled. Maintenance is minimal; wiping the smooth, corrosion-resistant surfaces with a dry cloth is typically sufficient to keep it in good condition for repeated training cycles.Q: Why is a sectional view beneficial for learners?
A: The cut-section design offers direct visualization of internal components, making abstract concepts tangible, improving retention, and helping students grasp functional relationships within pneumatic systems.Q: What are the key benefits of using this model for vocational and engineering education?
A: Benefits include enhanced understanding of pneumatic principles, increased engagement through hands-on study, durable construction for repeated classroom use, and an effective teaching aid for instructors explaining technical concepts.Tell us about your requirement
