Electrical Machine Trainer

Product Description

Technical Specifications:

Control Panel housed in a wooden cabinet in tapered shape for better view angle. Meters are mounted on thick Bakelite front panel with connection Terminals.

Meters

• 1 No. Voltmeter range 0-500V AC, Size 96X96mm
• 3  Nos. Ammeter range 0-3A AC, Size 96X96mm
• 1 Nos. Frequency meter range 45-55 Hz Size 96X96mm
• 2 Nos. Voltmeter range 0-300V DC, Size 96X96mm
• 1 No. Ammeter range 0-10A DC, Size 96X96mm
• 1 No. Ammeter range 0-5A DC, Size 96X96mm
• 1 No. Voltmeter range 0-300V AC, Size 96X96mm
• 1 No. Ammeter range 0-10A AC, Size 96X96mm
• 1 No. Wattmeter range 0-1000W, Size 96X96mm

DC Source : 0 - 250V DC/2 Amps (Variable)

DC Drive : 1 No. Thyristorized DC Drive For Speed Control

Protections : 2 No. MCB / DP+TPN of Range 16AMP

Power requirement : 220~240V AC , 50Hz, Single Phase

Standard Accessories:

DC Shunt Motor 2HP 220V, Coupled with DC Shunt Generator

0.5KW 220V With AC Alternator 0.5 KW & AC Induction Motor

1HP 220VAC

Technical Specifications:

• DC Shunt Motor
• Capacity : 2HP
• Cage : Steel Body
• Class : E Class
• RPM : 1500 Approx
• Shaft : Single
• Current : 7 Amp Max
• Input Terminal : Armature (A1, A2) , Field (F1, F2)
• Power Requirement: 220V DC, Single Phase

• DC Shunt Generator
• Capacity : 0.5 KW
• Cage : Steel Body
• Class : E Class
• RPM : 1500 Approx.
• Shaft : Single
• Current : 2.2 Amp Max
• Input Terminal:Armature (A1 and A2), Field (F1 and F2)
• Output Voltage:220~ 240V DC, Single Phase
• AC Alternator
• Capacity: 0.5 KW
• Cage : Steel Body
• Class :E Class
• RPM :1500 Approx.
• Shaft :Single
• Current : 2.2 Amp Max
• Input Terminal : R, Y, B and neutral with F1 and F2(Field Terminal)
• Output Voltage : 415~440V AC, 50Hz, Three Phase
• Single Phase Induction Motor
• Capacity: 1 HP
• Cage : Steel Body
• Class :E Class
• RPM :1500 Approx.
• Shaft :Single
• Current : 6 Amp Max
• Input Terminal: Phase & Neutral
• Input Voltage :220~240V AC, 50Hz, Single Phase
• Tachometer(ME6236B):
• 1 No.Patchcords:10 No.
• Instruction Manual:1 No.

Versatile and Safe Laboratory Trainer

This trainer facilitates in-depth study of single and three-phase electrical machines. Robust safety features, including overload and short circuit protection, and emergency stop, ensure secure operation. Modular and detachable machine modules make it adaptable to different experimental needs and easy to maintain.


Comprehensive Experimentation and Measurement

Equipped with standard test points, banana sockets, and a digital tachometer for RPM indication, the EMT-2948502 allows users to access and measure electrical signals precisely. The inclusion of experiment charts, manuals, and connecting wires provides all necessary resources for clear, guided learning.


Durable Construction for Continuous Use

Constructed with powder-coated mild steel cabinets, heavy-duty mounting, and high-grade materials, this trainer is built for long-term use in demanding educational environments. Its modular design supports easy upgrades and maintenance, while operating efficiently in a wide ambient temperature range.
