PNEUMATIC TRAINER KIT WITH WORK STATION

PNEUMATIC TRAINER KIT WITH WORK STATION

Product Details:

  • Material Stainless Steel
  • Usage For Industrial Use
  • Voltage 220 Volt (v)
  • Classification PNEUMATIC TRAINER
  • Color Red & White
  • Supply Ability : 10 Unit Per Week
1000 Onwards INR/Unit
X

Price And Quantity

  • 1 Unit
  • 1000 Onwards INR/Unit

Product Specifications

  • Red & White
  • For Industrial Use
  • 220 Volt (v)
  • PNEUMATIC TRAINER
  • Stainless Steel

Trade Information

  • 10 Unit Per Week
  • 15 - 30 Days
  • Corrugated Box
  • All India

Product Description

Me 7642 - Pneumatic Trainer Kit Withwork Station

Pneumatic Trainer Kit With Work Station.

Pneumatic Trainer Kit Consisting Of

Compressor Unit

Pneumatic Matching Component And Accessories

Power Supply Unit

Pneumatic Workstation With Pneumatic Components In Working Condition

Carrier For Mounting Components Such As Pb & Relay Box

Cut Section Model Of Pneumatic Components.

Compressor Unit:

-Type: Belt Driven Single Stage.

-Capacity : 45 Ltr

-Motor : 0.5 Hp

-Working Pressure : 08 Bar

-Power Supply : 230 Vac

-With Pressure Gauge, Safety Valve, Air Control Valve, Drain Valve, Belt Guard,Water Separator & Pressure Switch

Pneumatic Trainer Kit, Each Consistingof The Following Machine Components And Accessories.

Single acting Cylinder

  •  Max. Stroke Length 50mm,
  •  Bore Dia 20       Mm: 1 No
  • Double acting Cylinder
  •  Max. Stroke Length 100mm
  •  Bore Dia : 20 Mm
  •  Magnetic Type: 1 No

3/2-Way Valve Manually-Actuated,Normally Closed: 2 Nos

3/2-Way Valvepneumatically-Actuated, Spring Return: 1 No

One-Way Flow Control Valve: 2 Nos

5/2-Way Valve With Manually-Operatedswitch: 1 No

5/2-Way Valvepneumatically-Actuated, Spring Return: 1 No

5/2-Way Pneumatic Actuated Valvedouble Pilot: 1 No

3/2 Position Palm Operated Valve: 1no

3/2-Way Roller Lever Valve Directactuation Normally Closed: 2 Nos

Shuttle Valve (OR): 1 No

 two-Pressure Valve (AND): 1 No

 air Filter Regulator: 1 No

Pressure Gauge 0-16 Bar: 1 Nos

Manifold With Self-Closing Nrv,6-Way: 1 No

5/2-Way Roller Lever Valve Directactuation Normally Closed: 1nos

Proximity Sensor: 4 No

Exhaust Silencer: 5 No

Pushbutton Station Forelectrical Signal Input With 3 Illuminated Momentary-Contact Switches (1 No + 1nc) And 1 Illuminated Maintained-Contact Switch (1 No + 1 Nc),      Contact Load 2a 1no

Relaystation With 3 Relays Each With 4 Contact Sets (3NO+1NC Or Change-Over Type), 5a: 1 No

3/2-Way Single Solenoid Valve Withled: 1 No

5/2-Way Single Solenoid Valve Withmanual Override And   Led: 1 No

5/2-Way Double Solenoid Valve Withmanual Override And Led: 1 No

Pneumatic Rotary Actuator 180 Degmovement.: 1 No

Pneumatic Motor With Minimum Rpm20000 Or More: 1 No

Power supply Unit

  •  Input Voltage 85  265 V Ac
  •  Output Voltage: 24 V Dc
  •  Output Current: Max. 4.5a
  •  Short-Circuit-Proof.: 1no
  • Plcwith Ethernet Communication:
  •  N. Of Input : 14 Nos.
  •  No Of Output : 10 Nos.
  •  Operating Voltage : 24vdc
  • Programmingcable Between Plc And Pc:
  •  Type : Ethernet Cable
  •  Length : 3 Meter



Softwaretool For Programming Plc: Programming Through Pc

All Abovecomponents In Working Condition To Understand Design And Working Principal Ofpneumatic Components And Circuits.

Simulationsoftware Provided To Understand Working Principal Of Pneumatic Components, Itssymbols And Circuits.



Pneumatic Workstation

40square Mm Aluminium Profile Legs, Wooden Work Surface, And One Pedestal Drawerunit Having 5 Drawers, Each With Handles And Individual Locks, On Metallic Fullpanel Drawer Slide:

(1)Work Table  Size (Approx.)L1200mmxw900mmxh900mm With Four Castor Wheels Including Two Lockable Wheels Atthe Front Side.

Aluminumprofile Leg 40 Mm Sq Wooden Work Surface.

Onepedestal Drawer & Five Drawers With Handle And Locks.

Verticalprofile Plate Anodized Aluminum 1100x700 Mm With Carriers Mounting Frames Andmounting Accessories (To Be Fitted Onto The Pneumatic Workstation) Andcomponent Easily Removable When It Need To Remove From Profile Plate.

Everypneumatic Component Having Pneumatic Push Pull Connector On It So That It Canperforms Various Pneumatic Circuits With Different Connections.

Andit Also Consist Of One Relay Box (made Up Of Ms) With Various Pushbuttons (PB),lamps And Power Supply To Perform Various Electro Pneumatic Experiments.

(2)Drawer  Size (Approx.)  L460mmxw495mm Xh158mm Each And Overall Size Ofdrawer Unit. (Approx.) - L-470mmx W-495mmxh-825mm.

3drawer Slide Height (Approx.) 85mm.

4carrier For Mounting Components, Such As Pb & Relay Boxes.


5. List Of Cut Section Pneumaticcomponents:

  • Single Acting Cylinder Max. Strokelength 50 Mm, Bore Dia 20 Mm: 1 No
  • Double Acting Cylinder Max. Strokelength 100 Mm, Bore Dia 20 Mm, Magnetic Type: 1 No
  • 3/2-Way Valve Manually-Actuated,Normally Closed: 2 Nos
  • 3/2-Way Valvepneumatically-Actuated, Spring Return: 1 No
  • One-Way Flow Control Valve: 2 Nos
  • 5/2-Way Valvepneumatically-Actuated, Spring Return: 1 No
  • 5/2-Way Pneumatic Actuated Valvedouble Pilot: 1 No
  • 3/2-Way Roller Lever Valve Directactuation Normally Closed: 2 Nos
  • Two-Pressure Valve (AND): 1 No
  • Pressure Gauge: 1 Nos
  • Manifold With Self-Closing Nrv,6-Way: 1 No
  • 3/2-Way Single Solenoid Valve Withled: 1 No
  • 5/2-Way Double Solenoid Valve Withmanual Override And Led: 1 No

Pneumatic Trainer With Toolkit To Fitting Of Pneumatic Components, & Assorted Pu Pipe Provided Withsuitable Size And Length To Conduct The Experiments.
