Orifice Meter Test Rig Product Specifications

Temperature Range Ambient to 70C

Type Flow Measuring Apparatus

Weight Approx 45-60 kg

Accuracy 1%

Display Type Analog or Digital (as per model)

Usage Engineering Institutes, Laboratory Experimentation, Educational Demonstration

Dimension (L*W*H) 1000 x 500 x 1200 mm

Capacity 40 LPH to 200 LPH (customizable)

Core Components Orifice plate, Differential manometer, Sump tank, Collecting tank, Water Supply Pump

Feature Portable, Easy to install, Corrosion resistant

Equipment Materials Mild Steel (Powder Coated), Stainless Steel (Contact Parts)

Model No OME-40/OME-100

Power Source Electric

Frequency 50 Hz

Measurement Range Up to 200 LPH

Automation Grade Manual/Semi-Automatic

Voltage 230V AC, Single Phase

Product Description

Experience the preeminent Orifice Meter Test Rig, meticulously crafted for laboratory experimentation and educational demonstration. Boasting a majestic combination of a 0.25 HP centrifugal pump and U-tube water-filled manometer, this polished apparatus ensures accurate measurement from 40 to 200 LPH. Made with corrosion-resistant borosilicate glass or SS304, it features instant savings on service with national support and overload protection. Shop now for a portable, easy-to-install, and customizable solution ideal for engineering institutes. Order today to benefit from an analog/digital display with 1% accuracy and robust construction.

Versatile Application & User Base

The Orifice Meter Test Rig is predominantly used by engineering institutes and laboratories for flow measurement experiments and educational demonstrations. Its polished, table-top design is applicable to both practical coursework and experimental research, offering precise flow quantification via a volumetric tank and stopwatch method. Application is straightforward: set up the apparatus on a flat surface, fill the sump, and start the experiment with minimal supervision, ensuring convenience and reliability in teaching or research settings.

Certifications, Packaging, and Delivery Information

Our Orifice Meter Test Rig comes certified for laboratory and educational use, ensuring compliance with industry standards in India. Goods are securely packaged for shipment, mitigating transit damage and safeguarding your outlay. Each unit is thoroughly tested before dispatch. Expect standard delivery time of 2-3 weeks from order confirmation, with freight charges calculated based on destination. Order today for prompt, reliable shipping and after-sales support throughout India.

FAQ's of Orifice Meter Test Rig:

Q: How do you set up the Orifice Meter Test Rig for laboratory use?

A: To set up the Orifice Meter Test Rig, place it on a stable tabletop, connect the power supply, fill the sump tank with water, and ensure the manometer and collection systems are connected securely. Follow the user manual for detailed installation steps.

Q: What core components are included in the Orifice Meter Test Rig package?

A: The test rig includes an orifice plate, differential manometer, sump tank, collecting tank, water supply centrifugal pump, drain valve, and all necessary fittings, ensuring complete functionality for flow measurement experiments.

Q: When is it necessary to use a digital display model over an analog one?

A: A digital display model is recommended when precise and immediate numerical readings are needed for data collection, while the analog version suits basic demonstration and educational scenarios where high precision is less critical.

Q: Where is the Orifice Meter Test Rig manufactured and supplied?

A: The rig is manufactured and supplied by a leading exporter and supplier in India, with national service support and shipping available across the country.

Q: What are the chief benefits of choosing this flow measuring apparatus for educational institutions?

A: This apparatus offers dependable accuracy (1%), overload protection, customizable flow range, corrosion resistance, and portable design, making it ideal for hands-on student learning and reliable laboratory performance.
