Losses Due to Pipe Fitting, Sudden Enlargment & Contraction

Product Description

Losses Due to Pipe Fitting, Sudden Enlargment & Contraction is a widely demanded scientific instrument for which we are considered a respected supplier for our clients. It is precisely designed using supreme quality raw material and hi tech machinery at our vendors unit under the expert supervision and guidance. Losses Due to Pipe Fitting, Sudden Enlargment & Contraction is hence known for its quality, performance, durability and accuracy. We have gained high rising demands for the same from global markets.

Experimental List

• To determine the friction factor for the pipes

Technical Specifications

• Pipe Line : 2Nos. with Different diameters
• a) 25mm Diameter (Elbow Less, Bend Less)
• b) 19mm & 45mm Diameter (sudden & Correlation)
• Inlet : Common for both pipes lines
• Pressure Measurement : 'U' Tube Differential Manometer 50cm
• Measuring Tank (Flow Measurement) : 300mm x 300mm x 300mm
• Sump Tank : 600mm x 300mm x 300mm
• Piping & Fittings : GI Material used
• Valves (Gunn Metal) : 4 Nos. for Drain, 1 No. for Water Control,1 No. for Byepass
• Stop Watch : Electronic
• Pump : 0.5HP Single Phase, 220VAC +10%(ISI)
• Tanks : Made of strong metal sheet
• Setup fitted on angle iron frame of size 1280 x 330 x 910 (mm)
• The whole set-up is well designed and arranged in a good quality painted structure
• Power Requirement : 220 VAC +10% , 50 Hz

Standard Accessories :

• Mercury for Manometer, Power cable, Instruction manual
