Impact of Jet of Vanes

Product Description

Over the years of dedication, we have been a well known supplier of Impact of Jet of Vanes to our globally scattered clients. We procure it from our dependable vendors who sturdily construct it using finest quality raw material and progressive machinery in compliance with the set industrial norms and standards. Impact of Jet of Vanes goes through various quality inspections to ensure high performance, quality, durability and a long service life. This has lead to its high rising demands by national as well as international clients.

Experimental List

To varify the momentum equation experimentally by impact of jet on different shapes

Technical Specifications

• Target (3 Nos.) : a) Hemispherical Cup 100mm Dia. b) Flat Plate 50mm Dia. c) Inclined Plate 45 Degree
• Nozzle (SS) : 10mm Dia, 75mm Long
• Weighing Scale : To measure jet force
• Jet Chamber : Clear Acrylic round pipe size 300mm x 250mm
• Measuring Tank (Flow Measurement) : 300mm x 300mm x 300mm
• Sump Tank : 600mm x 300mm x 300mm
• Piping & Fittings : : GI Material used
• Valves (Gunn Metal) : 2 Nos. for Drain, 1 No. for Water Control, 1 No. for Byepass
• Stop Watch : Electronic
• Pump : 0.5HP Single Phase, 220VAC +10%(ISI)
• Tanks : Made of strong metal sheet SS 304
• Setup fitted on angle iron frame of size 1280 x 330 x 910 (mm)
• The whole set-up is well designed and arranged in a good quality painted structure
• Power Requirement : 220 VAC +10% , 50 Hz

Standard Accessories :

Power cable, Instruction manual
