DC Position Servo Mechanism Trainer

Product Description

We are an eminent supplier of DC Position Servo Mechanism Trainer to our highly valued clients. It is precisely designed using high grade raw material and technologically advanced machinery at our vendors unit in compliance with the prevailing industrial norms and standards. We conduct various quality tests at our unit in order to assure utmost quality, durability, performance and easy operations of our DC Position Servo Mechanism Trainer. We offer it to our clients at pocket- friendly prices in the market.

Objective :

• Study the working and principle of DC Servo Motor
• Servo Potentiometer for position sensing
• Servo potentiometer as an error detector

Technical Specifications :

• Control Unit
• Inbuilt fixed DC Regulated
• power supply : + 12VDC
• Inbuilt fixed DC supply : 20 VDC
• Null meter for measurement of angle
• Control Switches : 5 Nos.
• Test Point : 5 Nos.
• Front panel of 400mm x 225mm & mounted on light weight shock proof plastic cabinet
• Circuit diagram printed on panel & all important test points are brought out on front panel
• Power requirement : 220 VAC +10%, 50Hz
• Weight : Kg Approx.
• Dimensions (mm) : 430( L) x 230(B) x 90(H)
• Motor Unit
• DC Servo Motor having both side shaft. One end coupled with Techo generator & other end coupled loading arrangement with potentiometer

Standard Accessories :

Motor Unit, Power Chord, Patch Chords & Instruction Manual
