4-Bit Shift Registers

4-Bit Shift Registers

Get a Price/Quote

Product Details:

  • Usage For Testing Purpose
  • Product Type Shift Registers
  • Material PVC
  • Color Black
  • Equipment Materials Glass Epoxy Front Panel with PVC Box
  • Type Educational Lab Trainer Module
  • Temperature Range -5 to 45 Celsius (oC)
  • Click to View more
Request to Call Back Send Inquiry
X

Price And Quantity

  • 1 Unit
  • INR/Unit

Product Specifications

  • Shift Registers
  • PVC
  • Black
  • Glass Epoxy Front Panel with PVC Box
  • Educational Lab Trainer Module
  • For Testing Purpose
  • -5 to 45 Celsius (oC)

Trade Information

  • 10 Unit Per Week
  • 15-30 Days
  • Carton Box
  • All India
  • ISO Certificate

Product Description

ME 716- 4-Bit Shift Registers

The instrument has been designed to study :

A.Universal shift register using IC 74194

B.Serial in,Parallel out shift register using IC 7495

C. Parallel in,Parallel out shift register using IC 7495

D. Parallel in,Serial out shift register using IC 7494

E. Serial in,Serial out shift register using IC 7494



Output voltage(Regulated) : 5VDC (Internally connected)

Housed in PVC cabinet, circuit diagram printed, connections of Ics (74194, 7495 & 7494),logic inputs, output indicators & test points brought out at Glass Epoxy(PCB) front panel.

Also provided with patch chords & instruction manual.

ME 716A- Universal shift registers using IC 74194

ME 716B- shift registers using IC 7495 (SIPO & PIPO Mode)

ME 716C-Shiftregisters using IC 7494 (PISO & SISO Mode)
