ME 720-16 to 1 Multiplexer & 1 to 16 Demultiplexer
The instrument has been designed to study of multiplexers & de-multiplexers for different Inputs
Types of Multiplexer : 2:1 Multiplexer, 4:1Multiplexer, 8:1 Multiplexer., 16:1 Multiplexer.
Types of Demultiplexer: 1:2 Demultiplexer.,1:4 Demultiplexer., 1:8 Demultiplexer, 1:16 Demultiplexer.
Output voltage(Regulated) : 5VDC (Internally connected)
Housed in PVC cabinet, circuit diagram printed, connections of ICs(74150,74154), logic inputs, output indicators & test points brought out at Glass Epoxy (PCB)front panel.
