Study of Compensation Network

Study of Compensation Network
Study of Compensation Network
Send Inquiry
Product Code : ME 1114
Price And Quantity
  • Minimum Order Quantity
  • 1
  • Unit of Measure
  • Unit/Units
  • Price Range
  • 1000.00 - 200000.00 INR
Product Specifications
  • Dimension(L*W*H)
  • 430 x 230 x 90 Millimeter (mm)
  • Usage
  • For Testing Purpose
  • Power
  • 220 VAC +10%, 50Hz
  • Product Type
  • Compensation Network
  • Weight
  • 1 Kilograms (kg)
  • Material
  • Mild Steel
  • Color
  • White
  • Display Type
  • Digital
Product Description

Owing to our rich industrial experience, we have been a well established supplier of Study of Compensation Network to our widely scattered clients. It is precisely designed using fine quality raw material and progressive machinery at our unit in adherence with the prevailing industrial norms and standards. Study of Compensation Network stands high on performance, quality, reliability, durability and has a long functional life. We hence offer this to our clients at cost- effective prices in the market among our competitors.



Objective :

To study lead , lag , limited lead , limited lag and lead - lag compensating network Theory Active & Passive Networks

Technical Specification

  • Inbuilt fixed output
  • DC Regulated power Supply : + 12VDC & 5VDC
  • Digital Phase angle meter : 0-360 degree
  • Digital AC Voltmeter : 0.1V to 5V
  • Compensation network using
  • Operational Amplifier : Lead, lag, limited lead, limited lag and lead-lag
  • Inbuilt all pass Network
  • Power requirement : 220 VAC +10%, 50Hz
  • Weight : 1.0Kg Approx.
  • Dimensions (mm) : 430( L) x 230(B) x 90(H)

Standard Accessories :

Power Chord, Patch Chords & Instruction Manual, Three pin female metal connector cable.
Trade Information
  • Payment Terms
  • Cash in Advance (CID), Cash Advance (CA)
  • Supply Ability
  • 10 unit Per Week
  • Delivery Time
  • 15-30 Days
  • Packaging Details
  • Carton Box
  • Main Domestic Market
  • All India
