AC Servo Speed Torque Characteristic Trainer

Product Description

AC Servo Speed Torque Characteristic Traineris a widely demanded product for which we are considered a respected supplier for our clients. It is used for different purposes in scientific industry. We obtain it from our reliable vendors who make use of premium quality material and machinery for makingAC Servo Speed Torque Characteristic Trainerin adherence with the set industrial norms and standards. This has gained us huge applaud from our clients in the form of highly increasing demands.Objective : Study the speed torque characteristics of AC servo motorStudy the speed variation & speed measurement of AC servo motorTo plot graph between speed vs torque of AC servo motorTechnical Specifications : Control UnitIn built fixed AC power supply for AC servo motor: Approx 100VAC/ mA for reference winding0 ~ 60VAC/mA for control windingRPM meter provide on board for speed measurementAmmeter provided on board for load current measurementLoading arrangement provided for Servo MotorFront panel of 400mm x 225mm & mounted on light weight shock proof plastic cabinetCircuit diagram printed on panel & all important test points are brought out on front panelPower requirement : 220 VAC +10%, 50HzWeight : Kg Approx.Dimensions (mm) : 430( L) x 230(B) x 90(H)Motor UnitAC Servo Motor with 2 phase windings having both side shaft coupled with loading arrangement on one end and 20 holes disc provided on other end. Photoelectric pickup and photo transistor act as a optocoupler in between disc for speed sensingStandard Accessories : Motor Unit, Power Chord, Patch Chords & Instruction Manual
