Sensor Trainer Kit

Sensor Trainer  Kit
Sensor Trainer Kit
Send Inquiry
Product Code : ME 1068
Price And Quantity
  • Minimum Order Quantity
  • 1
  • Unit of Measure
  • Unit/Units
  • Price Range
  • 1000.00 - 200000.00 INR
Product Specifications
  • Color
  • Red and Black
  • Product Type
  • Trainer Kit
  • Power
  • 220 AC +10%, 50Hz Volt (v)
  • Material
  • SS Steel
  • Usage
  • To Study Signal Output & Signal Conditioning Circuitry
  • Display Type
  • Digital
Product Description

Owing to our rich industrial experience, we have been a noted supplier of Sensor Trainer Kit to our widely spread clients. It is sturdily constructed using best quality raw material at our vendors unit in compliance with the prevailing global norms and standards. We have gained huge applaud from our clients for the quality, durability, performance and accuracy of our Sensor Trainer Kit in the form of highly increasing demands. We offer this kit to our clients at highly affordable prices.


  • To study working principle of different types of Sensors (transducers).
  • To study practical & Theoretical Aspects of different types  Sensors (transducers).
  • To study signal output & signal conditioning circuitry different types Sensors (transducers).

Technical Specifications:

  • DC Regulated Power Supplies
  • +5VDC(fix) for LVDT,
  • +5VDC(fix) for Thermocouple,
  • +5VDC(fix) for RTD,
  • +5VDC(fix) for Strain Gauge & Load Cell,
  • +5VDC(fix) & 0-12VDC(variable) for Speed Sensor circuit &
  • +9VDC(fix) & +5VDC(fix) for Smoke Sensor Circuit
  • +5VDC(fix) for all DPMs.

Separate mechanism for LVDT (LVDT Jig) with 5 pin connector, is provided, to be connected at "LVDT INPUT"    connector provided in its signal conditioning circuit.

Separate speed sensor, is provided, to be connected at "SPEED SENSOR INPUT" connector provided in "SPEED SENSOR "circuit.

Separate smoke sensor, is provided, to be connected at "SMOKE SENSOR INPUT" connector provided in "SMOKE SENSOR ALARM" circuit.

Separate Load Cell & Strain Gauge sensors, are provided, to be connected at "A,B,C & D" sockets provided in its circuit.

Separate Thermocouple sensor (K-type) & RTD(PT-100)  sensor along with their associated accessories, are provided, to be connected at "THERMOCOUPLE INPUT" & at "RTD INPUT" sockets respectively provided in their signal  conditioning circuits.

Three nos. of Digital Panel Meter (DPMs) are provided on front panel in their respective circuits for observing direct output of the respective experiments. One DPM fitted separately (provided with INPUT sockets "+" & "-") at top     right corner can be used both for Thermocouple & RTD experiment with the help of "THERMOCOUPLE RTD" toggle switch.

Circuit diagrams for different experiments are printed on front PCB panel & important Test Points (TPs) are extended to the front panel.

Glass Epoxy PCB used as front panel of 458mm x 458mm & mounted on shock proof wooden box.

Power requirement: 220V ac +10%, 50Hz
