Refrigeration Test Rig

Product Description

Over the years of dedication, we have been a reputed supplier of Refrigeration Test Rig to our highly respected clients. It finds application in scientific industry for varied purposes. Supreme quality material and ultra modern machinery is used in its making as per the industrial set norms and standards. We conduct various quality tests prior to dispatch at our unit to assure serving our clients with a flawless range of Refrigeration Test Rig. We offer this rig to our clients at pocket- friendly prices.

Technical Specification:-

• ISI Kirloskar/ Tecemshah Hermatically sealed Compressor
• Capacity :1/3 HP with suitable cooling fan & fins and copper tube air cooled
• Expansion device : capalliary tube & filters/driers
• Pressure gauge : 2 nos. for high & low pressure
• Service valves : 4 nos. Hand set valves
• Evaporator coil : suitable for above compressor immersed in water tank
• Refrigerant : Freon-12/134a
• Rotameter : suitable for compressor capacity, glass tube Rotameter to measure the flow of liquid refrigerant gas

Control unit

• Main switch
• Voltmeter digital type-1 no.
• Amp. meter digital type-1 no.
• Energy meter for compressor input
• Switch indication lights etc.
• Digital temp. indicator-5 nos.
• Temperature sensor (thermocouple)-5 nos.

Voltage : single phase 220v 50 Hz. AC supply

The unit is mounted on a sturdy frame with control panel.
