Ice Plant Test Rig Product Specifications

Core Components Compressor, Condenser, Expansion Valve, Evaporator, Controls

Equipment Materials Stainless Steel, Mild Steel, Copper Tubing

Model No IPTR-2024

Measurement Range -20C to +50C

Temperature Range -10C to +10C

Accuracy 1C in temperature measurement

Automation Grade Semi-Automatic

Feature Corrosion-resistant, Easy to Operate, All Necessary Controls and Protections

Capacity 3 TR (Tons of Refrigeration)

Type Educational/Testing Equipment

Usage Laboratory, Educational Demonstration, Research

Weight Approx. 150 kg

Power Source Electric

Dimension (L*W*H) 1800 mm x 800 mm x 1700 mm

Frequency 50 Hz

Voltage 220-240 V

Display Type Digital and Analog Gauges

Installation Table Top/Self-Standing

Training Manual Supplied

Insulation PUF Insulated Tubing and Chamber

Compressor Type Hermetically Sealed

Refrigerant Type R134a / R404A

Application Heat Transfer, Refrigeration Cycle Study, COP Estimation

Safety Features Overload Protection, High/Low Pressure Cut-off

Flow Measurement Integrated Rotameter for Brine/Coolant

Data Logging Provision for Data Logging (optional USB/PC connectivity)

Evaporator Type Shell & Tube Type

Control Panel With Start-Stop, Digital Indicators, and Safety Features

Type of Ice Produced Block Ice

Testing Standard Complies with IS 16069:2013

Condenser Type Air Cooled

Product Description

Experience the sizzling efficiency of the Blue-ribbon IPTR-2024 Ice Plant Test Rig! Designed for breathtaking performance, this noble equipment operates with R134a/R404A refrigerants and a hermetically sealed compressor, ensuring favorable reviews from leading laboratories and research centers. With a feature-rich control panel (start-stop, digital indicators, safety protocols), corrosion-resistant build, and precision components like a shell & tube evaporator and air-cooled condenser, it delivers block ice production with remarkable accuracy (1C). Get it now and elevate your refrigeration cycle studies, COP estimation, and demonstration sessions!

Maximum Performance & Competitive Features

The Ice Plant Test Rig stands out with an impressive 3 TR capacity and advanced features like integrated rotameter for accurate flow measurement, digital/analog gauges, and a semi-automatic operation mode. Suitable for heat transfer analysis, educational demonstrations, and R&D applications, it impresses with its stainless steel build, corrosion-resistant protection, and compliance with IS 16069:2013 testing standards. Its ease of use and robust safety measures make it a preferred choice for laboratories seeking superior results.

Sample Policy, Payment & Delivery Assurance

We offer a clear sample policy on the Ice Plant Test Rig to guarantee customer satisfaction before purchase. Competitive sale price options and flexible payment terms ensure smooth transactions for clients and institutions across India. Each unit is securely shipped with meticulous handling, minimizing transport risks. Expect your shipment to be delivered promptly, adhering to established delivery timelines, and backed by our commitment to safe, reliable, and fully insured logistics.

FAQ's of Ice Plant Test Rig:

Q: How does the Ice Plant Test Rig enhance educational and laboratory demonstrations?

A: The Ice Plant Test Rig is engineered for interactive learning and precise experimentation, allowing users to study refrigeration cycles, perform heat transfer analysis, and estimate the coefficient of performance (COP) with real-time data and digital indicators.

Q: What refrigerants can be used with the Ice Plant Test Rig?

A: This rig supports both R134a and R404A refrigerants, catering to various research and demonstration requirements while maintaining optimal safety and performance benchmarks.

Q: Where can the Ice Plant Test Rig be installed and used?

A: The equipment is versatile, suitable for table-top or self-standing installation, making it ideal for laboratories, universities, research centers, and technical institutions.

Q: What are the primary safety features incorporated into the Ice Plant Test Rig?

A: Safety is paramount: the rig is equipped with overload protection, high/low pressure cut-offs, and includes PUF insulated tubing and chambers to ensure operational safety and measurement reliability.

Q: What is the process for integrating data logging and PC connectivity?

A: An optional provision is available for USB or PC connectivity, allowing seamless data logging to record readings for analysis, reporting, or classroom demonstrations.

Q: When is the Ice Plant Test Rig shipped after placing an order?

A: Once your order and payment are processed, the rig is packed securely and shipped within the promised delivery timeframe, ensuring quick and safe arrival.
