Owing to our rich industrial experience, we have been a trusted supplier of Motor Shunt DC 220 Volt, 2 to 3 HP to our highly esteemed clients. It is an instrument used in electric machine lab. We obtain it from our dependable vendors who make use of fine quality raw material and advanced machinery at our unit in adherence with the industrial set norms and standards. Motor Shunt DC 220 Volt, 2 to 3 HP has gained us huge appreciation from our clients leading to high rising demands in the market.
TECHNICAL SPECIFICATION :
D.C. Shunt motor 3 H.P., 220 volts,1500 R.P.M., continuous rating class of insulation 'B' S.P.D.P. Type, Horizontal foot mounted, confirming to , All the terminals are brought out to the terminal box.
Control Desk :
- The Control desk consist of an Instrument panel and working area.
- The control desk made of 30mm x 30mm x 1.6mm tubular mild steel and MS sheet of 1 mm thickness, Siemens Grey colour powder coated with wooden top on the working area.
- The overall dimensions W = 900 mm ; D = 625 mm ; H = 1500 mm.
- The Box type Instrument Panel above the working area and of size W = 900 mm ; D = 250 mm ; H = 750 mm & Front side of 6mm thick bakelite sheet of brown colour and fitted at inside of the tube structure.
- All other sides made of MS sheet, Two sides of the panel are to be perforated for air ventilation.
- Back side in the form of hinged door with suitable locking arrangement.
- The working area top fitted in front of the Instrument Panel at a height of 750 mm from bottom.
- The top of W = 900 mm x D = 375mm and made of 19mm marine plywood fitted with 3 mm Ivory colour edhylam sheet on top.
- The three sides of the working top lipped using 22mm x 6mm teakwood lipping patti.
- 30 A. Educational type backelite insulated banana terminals provided for supply and motor connection.
- Circuit diagram of panel provided inside the panel.
- All accessories connected with internal wiring ferrules etc.
The Instrument Panel consist of following accessories :
- Three point D.C. starter suitable for above motor, flush mounted : 1 no.
- D.P.S.T. Knife Switch. suitable for above motor : 1 no.
- Indicating lamp LED type 12 mm size for incoming and outgoing supply of the panel board : 2 nos.
- Voltmeter M.C. 0-300 volts D.C. size 96 x 96 mm Mars Make : 1 no.
- Ammeter M.C. 0-15 Amp. D.C. size 96 x 96 mm Mars Make : 1 no.
- Ammeter M.C. 0-1.5 Amp. D.C. size 96 x 96 mm Mars Make : 1 no.
- Field regulator suitable to keep constant rated R.P.M. of the motor at full load. : 1 no.
BASE PLATE :
Motor mounted on fabricated base plate of M.S.'C' channel size 75 x 40 x 6 mm thick. Base plate length 800 mm for generator coupling.
Motor painted with two coats of smoke grey oil paint, panel board and angle stand powder coated.
