ME571D - LCR Resonance Apparatus with Inbuilt Sine wave Oscillator
Objective:To plot frequency response & find out resonance frequency of LCR components when connected inseries & parallel.
Technical Specifications :
Meters : Rectangular 0-5V AC, 0-25mA AC
Inbuilt Sine wave oscillator : 100Hz to 100KHz (Variable),
Housed in PVC Cabinet, symbol diagram printed, connections of various components(Resistances, Capacitors, Inductance) & test points brought at Aluminum front panel.
Also provided with patch chords & instruction manual
