ME 525 IGBT Characteristics & Applications
Objective: Transfer characteristics & output characteristics of IGBT. applications to control the intensity of light of a lamp.
Output voltage (Regulated) : 0-10VDC, 0-20VDC, +12 V DC
Meters(Digital) : 0-20VDC (2 Nos.), 0-200mA DC
Housed in PVC cabinet, symbol diagram printed, connections of all important outputs& test point brought at Bakelite front panel.
