Frequency Counter 2.4GHz

Product Description

We are a well known supplier of Frequency Counter 2.4GHz to our highly reputed clients. They are used for refrigerator compressors as per the requirements. Our vendors use premium quality raw material and progressive machinery for its making in sync with the set industrial norms and standards. Our experts conduct various quality inspections to make sure that no compromise is done with the quality of our Frequency Counter 2.4GHz at any stage. We offer it at competitive prices in the market.

• 8 digit LED display with annunciators
• Two channels, operation mode memory
• Range and gate time adjustable
• High safety design

Input characteristics:

CH. A (50MHz~2.4GHz)

• Frequency range : from 50MHz to 2.4GHz
• Sensitivity : 50MHz~1.2GHz< 80m Vrms.
• Coupling : AC only
• Input impedance : 50M
• Max safety voltage : 3V

CH.B (0.01Hz~50MHz)

• Frequency Range : DC couple 0.01Hz to 100Hz
• AC couple 100Hz to 50MHz
• Sensitivity : “AC” 100Hz-50MHz< 80m Vrms
• “DC” 0.01Hz-1Hz< 500mVp-p,
• 1Hz-100Hz< 80m Vrms.
• Input impedance : 1M 
• Attenuator : X1, X20
• Max. safety voltage : 30V (DC/AC peak)

Resolution : Resolution depends on gate time control setting.

Time Base

• Short Time Stability : ± 3X10^-9/second
• Long Time Stability : ± 2X10^-8/month
• Temperature Drift coefficient: ± 1X10^-7, 10⁰c ~ 40⁰C
• Line Voltage Variation : ± 1X10^-7 for line voltage + 10%

Standard Accessories :

Power cable, BNC to Crocodile Clip Probes - 2Nos., Instruction manual
