Linear IC Trainer

Linear IC Trainer

Product Details:

  • Product Type IC Trainer
  • Usage For Testing Use
  • Color Black
  • Material Mild Steel
  • Equipment Materials Glass Epoxy Front Panel with PVC Box
  • Type Educational Lab Trainer Module
  • Temperature Range -5 to 45 Celsius (oC)
  • Supply Ability : 10 Unit Per Week
Price on Request INR/Unit
X

Price And Quantity

  • 1 Unit
  • Price on Request INR/Unit

Product Specifications

  • For Testing Use
  • Black
  • IC Trainer
  • Glass Epoxy Front Panel with PVC Box
  • Digital
  • -5 to 45 Celsius (oC)
  • Educational Lab Trainer Module
  • Mild Steel

Trade Information

  • 10 Unit Per Week
  • 15 - 30 Days
  • Carton Box
  • All India
  • ISO Certified

Product Description

ME 510  Linear IC Trainer

Objective:To study the characteristics and applications of the IC 741 & 555 more than 15 experiments can be performed

Technical Specifications:

Output voltages (Regulated) : 0-2.5VDC (2 nos), +-15VDC, 5VDC

Meters(Digital): 0-2VDC / 0-20VDC (Dual Range)

Housed in  PVC cabinet, symbol diagram printed,connections of various components ( IC 741, IC 555, 16 Pin IC Zip sockets,Resistances, Capacitors, Zener Diode, PN Junction Diode, LED's and Potentiometers.), all important outputs & test points brought at glass epoxy front panel.

Also provided with patch chords &instruction manual
