Directional Over Current Relay Testing Kit

Directional Over Current Relay Testing Kit

Product Details:

  • Color Black
  • Material Metal
  • Product Type Directional Over Current Relay Testing Kit
  • Voltage 220 Volt (v)
  • Type Testing Kit
  • Display Type Digital
  • Supply Ability : 10 Unit Per Week
1000 Onwards INR/Unit
X

Price And Quantity

  • 1 Unit
  • 1000 Onwards INR/Unit

Product Specifications

  • Digital
  • Testing Kit
  • Metal
  • Directional Over Current Relay Testing Kit
  • Black
  • 220 Volt (v)

Trade Information

  • 10 Unit Per Week
  • 15-30 Days
  • Corrugated Box
  • All India

Product Description

We are one of the leading suppliers of Directional Over Current Relay Testing Kit to our widely scattered clients. It is obtained from our dependable vendors who make use of supreme quality material and machinery in its making under the professional guidance and supervision. Our team also conducts various inspections to make sure that Directional Over Current Relay Testing Kit stands in sync with the prevailing global norms and standards. We offer it at highly economical prices in the market.

Objective:



  • To study the construction of relay
  • To obtain the time & current characteristics of a directional over current induction disc type relay

Technical Specifications:

  • Relay Type : Directional Over Current Relay (Electromechanical Induction Disc Type)
  • Terminals : 4mm Terminals for Trip, Current Output and Input
  • Meters (Digital) : 1No. AC Current Meter 0 – 20Amps & 1 No. Digital Timer .0001sec. to 9999sec. (Auto) (96mm x 48 mm)
  • Current Injector : Inbuilt variable current injector 20Amps to create Phantom Fault Current
  • Indicators : Provided on front panel for Mains, Current, Trip and Alarm
  • Switches : Provided on front panel for Mains, Timer Reset, Test Switch (ON/OFF)
  • Reversing Switch : To reverse the direction of current
  • Relay Circuit Diagram : Screen Printed on front panel
  • Weight : 40Kgs Approx.
  • Power Requirement : 220VAC +10%, 50Hz

Standard Accessories:

Power Cords, Patch Cords, Instruction Manual.
