Conversion of Galvanometer into Voltmeter & Ammeter

Conversion of Galvanometer into Voltmeter  & Ammeter

Product Details:

  • Usage For Testing Use
  • Product Type Galvanometer
  • Color Black & White
  • Material Mild Steel
  • Supply Ability : 10 Unit Per Week
Price on Request INR/Unit
X

Price And Quantity

  • 1 Unit
  • Price on Request INR/Unit

Product Specifications

  • Mild Steel
  • Black & White
  • Galvanometer
  • For Testing Use

Trade Information

  • 10 Unit Per Week
  • 15 - 30 Days
  • Corrugated Box
  • All India

Product Description

Over the years of dedication, we have been a trusted supplier of Conversion of Galvanometer into Voltmeter & Ammeter to our widely scattered clients. It is used in analog electronics lab as scientific instrument depending upon the diverse requirements of patrons. Finest quality raw material and ultra modern machinery is sued in making Conversion of Galvanometer into Voltmeter & Ammeter as per the industrial laid norms and standards. This has gained us high rising demands among that of our competitors. We offer it at highly economical prices in the market.

Objective:

Series resistance (for voltmeter) & Parallel shunts (for Ammeter) to Convert the galvanometer into voltmeter, milli ammeter.

Technical Specifications :

Inbuilt DC regulated power supply :

  • Output Voltage : 0-5VDC
  • On Board Analog Moving Coil Meters (60 mm x 35 mm )
  • Voltmeter : 0-5VDC
  • Ammeter : 0-250mA
  • Galvanometer : (30-0-30)20MicroA / Div.
  • Components Provided :
  • Resistance : R1=8.2 K ohm for 5V range,  R2=4.9K ohm for 3V range,  R3=2.4K ohm for 1.5V Range
  • Shunt : S1, S2, S3 are also mounted on the front panel.
  • High quality Aluminum used as front panel of 300mm x 220 mm & mounted on
  • light weight shock proof plastic cabinet
  • Circuit diagram printed on Aluminum Front Panel & all important test Points
  • are brought out on front panel
  • Power requirement : 230 VAC 10%, 50Hz.
  • Weight: 2.0Kg Approx.
  • Dimensions (mm): 330( L) x 225(B) x 75(H)

Standard Accessories

Power chord, Patch chords & Instruction manual.
