Analog Lab Trainer With Bread Board

Analog Lab Trainer With Bread Board Product Specifications

Color Black

Product Type Board

Weight 5 Kilograms (kg)

Usage Laboratory

Type Bread Board

Analog Lab Trainer With Bread Board Trade Information

Supply Ability 10 Unit Per Week

Delivery Time 15-30 Days

Packaging Details Corrugated Box

Main Domestic Market All India

Product Description

We are an eminent supplier of an extensive range of Analog Lab Trainer With Bread Board to our highly reputed clients. It is precisely engineered using best quality raw material and latest machinery at our vendorsâ€™ unit in adherence with the industrial laid norms and standards. It is an analog electronic lab instrument which is known for its high performance, quality, durability, easy usage and a long life. We offer Analog Lab Trainer With Bread Board to our clients at cost- effective prices.

Features :

Advanced lab trainer for students to perform more than 50 experiments of analog electronics
Compatible with optional ready to use experimental modules
Glass Epoxy PCB used as front panel of 300mm x 220mm & mounted on light weight shock proof plastic cabinet
On board power supplies, Function generator, and other input signals
Bread board provided
Supplied with connecting wires

Technical Specification :

Inbuilt Fixed DC Regulated Power Supplies :
Output Voltage : +5VDC /1Amp, +12VDC / 500mA, 0-+15VDC /500mA
Inbuilt AC Power Supply
Output voltage : 9-0-9V/500mA
Function Generator
Operating modes : Sine, Square, Triangular
Frequency range : 1Hz to 100KHz (with Adjustable Amplitude)
Modulation/Audio Generator
Operating modes : Sine, Square, Triangular
Frequency range : 1Hz to 10KHz (with Adjustable Amplitude)
Continuity Tester : For testing the continuity, provided with beeper sound
Power requirement : 230 VAC 10%, 50Hz.
Dimensions (mm) : 300( L) x 175(B) x 75(H)

Standard Accessories

5 mtr. hookup wire, 20 nos. Patch Chords with2mm banana plug on one end
Power Chord & Instruction Manual
Bread Board Strips 2 Nos vertically common strips (640 Tie points each)
4 Nos horizontally common strips(100 Tie points each)
